At A Glance

Model Name
Stiletto Extreme-4 LH
Item Number
2507
Country of Origin
Indonesia
Guitar Color Shown
Black Cherry (BCH)
Tuners
Schecter
Fretboard
Rosewood
Neck Material
Maple
Inlays
Pearloid & Abalone Vector
Scale
34" (863mm)
Neck Shape
Thin 'C'
Thickness
@ 1st Fret- .787" (20mm)/ @ 12th Fret- .866" (22mm)
Frets
24 X-Jumbo
Fretboard Radius
16" (406mm)
Nut
Graph Tech XL Black Tusq
Nut Width
1.496" (38mm)
Truss Rod
2-Way Adjustable Rod w/ 5/32" (4mm) Allen Nut
Guitar Colors
Black Cherry (BCH)
Hardware Color
Black Chrome
Top Contour
Flat Top
Dexterity
Left Handed
Construction
Bolt-on
Body Material
Mahogany
Top Material
Quilted Maple
Binding
Creme 1-ply
Bridge
Diamond Bass
Controls
Master Volume/Blend/Active 2-Band EQ
Bridge Pickup
Schecter Diamond Bass
Neck Pickup
Schecter Diamond Bass
Battery Compartment
9-volt Clip-in Battery Compartment
Knobs
Metal Knurled w/ Set Screw
Strings
Ernie Ball 4 String Super Long #2849 (.045-.105)
Case
SGR-UNIVERSAL BASS "Case Sold Separately"
Description

Schecter built the Stiletto Extreme-4 LH as a left-handed variant within its Stiletto Extreme series, positioning it as an active four-string bass with an emphasis on fast playability and aggressive tonal character. The model carried item number 2507 and was finished in Black Cherry.

Construction followed a bolt-on neck joint, pairing a mahogany body with a quilted maple top and creme 1-ply binding. The maple neck was profiled in a Thin 'C' shape, measuring .787" (20mm) at the first fret and .866" (22mm) at the twelfth, and was topped with a rosewood fretboard carrying 24 X-Jumbo frets at a 16" (406mm) radius. Pearloid and abalone vector inlays marked the positions. The nut was a Graph Tech XL Black Tusq unit at 1.496" (38mm) wide, and the truss rod was a two-way adjustable design accessed via a 5/32" (4mm) Allen nut. The 34" (863mm) scale ran to a Diamond Bass bridge finished in black chrome. Both neck and bridge positions housed Schecter Diamond Bass pickups, fed through a master volume, blend, and active 2-band EQ circuit drawing from a 9-volt clip-in battery compartment. Schecter tuners and metal knurled knobs with set screws completed the hardware complement. The instrument shipped strung with Ernie Ball 4-String Super Long #2849 (.045–.105).

Owners sourcing replacement parts — including the Graph Tech XL Black Tusq nut, Diamond Bass bridge saddles, or active EQ components — should consult a qualified bass technician to confirm fit against the instrument's specific dimensions before installation.
