At A Glance

Model Name
Johnny Christ Bass
Item Number
213
Country of Origin
South Korea
Guitar Color Shown
Satin Black (SBK)
Tuners
Grover
Fretboard
Ebony
Neck Material
Maple
Inlays
Gold Bone Crosses w/Deathbat at 12th Fret
Scale
34" (863mm)
Neck Shape
C'
Thickness
@ 1st Fret- .866" (22mm)/ @ 12th Fret- .925" (23.5mm)
Frets
21 Narrow X-Jumbo
Fretboard Radius
12" (305mm)
Nut
Graph Tech XL Black Tusq
Nut Width
1.653" (42mm)
Truss Rod
2-Way Adjustable Rod w/ 5/32" (4mm) Allen Nut
Guitar Colors
Satin Black (SBK)
Hardware Color
Gold
Top Contour
Flat Top
Dexterity
Right Handed
Construction
Bolt-on
Body Material
Ash
Bridge
Schecter Custom Bass String Thru (or Top Load)
Controls
Master Volume/Blend/2-Band EMG Active E/Q
Bridge Pickup
EMG MMCS
Neck Pickup
EMG 81
Battery Compartment
9-volt Clip-in Battery Compartment
Knobs
Metal Knurled w/ Set Screw
Strings
Ernie Ball 4 String Super Long #2849 (.045-.105)
Case
SGR-UNIVERSAL BASS "Case Sold Separately"
Description

Schecter built the Johnny Christ Bass as a signature instrument for Avenged Sevenfold bassist Johnny Christ, positioning it within the company's artist signature line as a purpose-built electric bass. The 213 carried the Satin Black finish and gold hardware combination that defined the model's aesthetic identity.

Construction followed a bolt-on neck joint, pairing a maple neck in a C profile with an ebony fretboard radiused at 12 inches. Twenty-one narrow extra-jumbo frets span a 34-inch scale, and the 42mm Graph Tech XL Black Tusq nut sets string spacing at the headstock. Grover tuners handle the Ernie Ball 4-string Super Long set. The ash body accepts the Schecter Custom Bass bridge, which supports both string-through-body and top-load stringing. Electronics consist of an EMG MMCS at the bridge position and an EMG 81 at the neck, governed by a master volume, a blend control, and a 2-band EMG active EQ — all powered by a 9-volt clip-in battery compartment. Hardware throughout is gold, including the metal knurled knobs secured with set screws. Inlays are gold bone crosses with a Deathbat motif at the 12th fret. The 2-way adjustable truss rod is accessed with a 5/32-inch Allen key.

Owners sourcing replacement hardware should note that the string-through/top-load bridge geometry and the 42mm nut width are the critical dimensions when locating compatible parts; a qualified guitar technician or luthier can confirm fit for any component swap or setup work.
