Schecter built the Damien Platinum-9 as a nine-string instrument within the Damien Platinum series, positioning it toward extended-range players seeking an active-pickup platform on a set-neck construction. The 30" (762mm) scale length accommodated the demands of the additional low string, and the body was constructed from mahogany with an arched top and silver/platinum multi-ply binding.
The neck was a three-piece maple assembly reinforced with carbon fiber rods, joined to the body via a set-neck joint with Ultra Access and profiled in a Thin 'C' shape measuring .787" at the first fret and .866" at the twelfth. The 24-fret rosewood fretboard carried a flat 20" radius, X-Jumbo frets, platinum bat inlays, a 2.5" graphite nut, and was strung with Ernie Ball's purpose-built nine-string 30" scale set. A dual two-way adjustable truss rod system with a 5/32" Allen nut ran through the neck. Both pickup positions were loaded with EMG 909 active humbuckers wired to a volume/tone/3-way switch layout with metal knurled knobs; a clip-in 9-volt battery compartment served the active electronics. Hardware throughout was finished in satin chrome, anchored by a Hipshot Hardtail bridge with string-through-body stringing and Grover tuners.
Owners requiring parts — including the Hipshot Hardtail bridge saddles, EMG 909 replacement pickups, or the Ernie Ball nine-string set — should cross-reference Schecter's original hardware specifications with current supplier catalogues; a qualified guitar technician can assist with setup, intonation, and truss rod adjustment on the dual-rod system.
Nothing in The Vault is for sale. These records exist so the instruments stay documented after the manufacturer moves on — and the most useful part of that record is what owners add to it.
The catalog shot showed one finish, under one light, a long time ago. Yours has been played. Photos from owners are what the next person finds when they are trying to identify a part, match a finish, or work out whether the one they just bought is really what the seller said it was.
Specs only go so far. What actually fits, what breaks first, what the factory got right and what everyone ends up changing — that lives with the people who own them, not in a datasheet. Post what you know and it stays on this page for whoever comes looking next.
