At A Glance

Model Name
V-1 Apocalypse FR
Item Number
3054
Country of Origin
South Korea
Guitar Color Shown
Red Reign
Tuners
Grover Rotomatic 18:1
Fretboard
Ebony
Neck Material
Maple/Padauk Multi-ply w/Carbon Fiber Reinforcement Rods
Inlays
Roman Numerals
Side Dot Markers
Glow in the Dark
Scale
25.5" (648mm)
Neck Shape
Thin 'C'
Thickness
@ 1st Fret- .787" (20mm)/ @ 12th Fret- .866" (22mm)
Frets
24 X-Jumbo Stainless Steel
Fretboard Radius
12"-16" Compound Radius
Nut
Floyd Rose 1500 Series
Nut Width
1.625" (41.3mm)
Truss Rod
2-Way Adjustable Rod w/ 5/32" (4mm) Allen Nut
Guitar Colors
Red Reign
Hardware Color
Satin Black
Top Contour
Flat Top
Dexterity
Right Handed
Construction
Set-Neck w/Ultra Access
Body Material
Swamp Ash
Binding
Black 1-ply
Bridge
Floyd Rose 1500 Series
Controls
Volume/Tone (Push-Pull)/3-Way Switch
Bridge Pickup
Schecter USA Apocalypse-VI™
Neck Pickup
Schecter USA Apocalypse-VI™
Knobs
Hipshot O-Ring
Strings
Ernie Ball Regular Slinky #2221 (.010-.046)
Case
SGR-8V "Case Sold Separately"
Description

Schecter positioned the V-1 Apocalypse FR Red Reign at the high-output, extended-range end of its Apocalypse series. The instrument was built in South Korea with a set-neck construction featuring Ultra Access, pairing a swamp ash body with a maple and padauk multi-ply neck reinforced with carbon fiber rods. The Red Reign finish was offered in satin black hardware.

The neck carries an ebony fretboard with a 12"–16" compound radius and 24 X-jumbo stainless steel frets, shaped into a Thin 'C' profile measuring .787" at the first fret and .866" at the twelfth. Roman numeral inlays mark the positions, with glow-in-the-dark side dot markers. The 25.5" scale runs from a Floyd Rose 1500 Series nut — 1.625" wide — to a Floyd Rose 1500 Series bridge, with Grover Rotomatic 18:1 tuners managing string tension. Both pickup positions carry Schecter USA Apocalypse-VI™ humbuckers, routed through a volume, a push-pull tone control, and a 3-way switch. Hipshot O-Ring knobs and black 1-ply body binding complete the hardware complement. Ernie Ball Regular Slinky .010–.046 strings were fitted at the factory.

Owners requiring setup work, Floyd Rose adjustments, or fretwork on the stainless steel frets should consult a qualified guitar technician familiar with double-locking tremolo systems.
