Dunlop EP103-U Echoplex Delay Pedal
Archive images of this model, kept as part of the record. Finishes, hardware and appointments changed across production runs, so yours may well differ in the details — and if it does, that difference is worth documenting. Add your photos to this record ›

At A Glance

Input Impedance
1 MΩ
Output Impedance
100 Ω
Max Input
+5 dBV
Max Output Level
+5 dBV
Noise Floor
-107 dBV
Sampling Rate
96 kHz
Current Draw
240 mA
Power Supply
9 volts DC
Description

Dunlop positioned the EP103-U Echoplex Delay as a digital recreation of the EP-3 tape echo unit, offering that unit's characteristic repeat tones without the maintenance demands of a tape cartridge system. It sat within Dunlop's effects line as a studio-grade delay pedal built around a straightforward control interface.

The EP103-U featured a hi-fi all-analog dry signal path, keeping the unaffected signal in the analog domain while the delay processing operated digitally at a 96 kHz sampling rate. A dedicated Age control allowed the owner to progressively degrade the character of the repeats, simulating the sonic behaviour of a worn tape echo unit. The pedal ran on 9 volts DC, drawing 240 mA, with an input impedance of 1 MΩ, output impedance of 100 Ω, maximum input and output levels of +5 dBV, and a noise floor of -107 dBV.

For questions about power supply compatibility, signal chain integration, or control calibration, a qualified guitar technician or electronics repair specialist will be best placed to advise.

Expert Analysis
Specifications
Input Impedance: 1 MΩ
Output Impedance: 100 Ω
Max Input: +5 dBV
Max Output Level: +5 dBV
Noise Floor: -107 dBV
Sampling Rate: 96 kHz
Current Draw: 240 mA
Power Supply: 9 volts DC
